Self-Hosting Vaultwarden on a Raspberry Pi (With a Disaster-Recovery Fallback)

Why I Self-Host My Password Manager

Password managers sit at the very center of modern digital life. They don’t just store passwords — they store identity, trust, and access. Relying entirely on a third party for that role is convenient, but it also creates a single external point of failure I don’t control.

This project documents how I self-host Vaultwarden (a lightweight Bitwarden-compatible server) on a Raspberry Pi 5, and how I designed a clean disaster-recovery fallback using a second Pi. The goal wasn’t novelty — it was reliability, security, and recoverability.

This post doubles as both a guide and a recovery runbook.

Architecture Overview

Primary Node (Always On)

• Raspberry Pi 5 (headless, Ethernet)
• Docker + docker-compose
• Vaultwarden bound to localhost
• HTTPS enforced via Caddy
• Local DNS via Pi-hole
• Persistent data stored outside the container

Secondary Node (Fallback)

• Raspberry Pi 5 (desktop Pi with 1 TB M.2 SSD)
• Vaultwarden installed but stopped
• Receives encrypted backups
• Can be promoted to primary in minutes

Only one Vaultwarden instance runs at a time to avoid database corruption.

Why Vaultwarden?

Vaultwarden is a community-maintained, Rust-based implementation of the Bitwarden server. Compared to the official server, it is:

• Extremely lightweight (ideal for ARM devices)
• Fully compatible with Bitwarden clients
• Easier to self-host securely
• Actively maintained

For single-user or small homelab use, it’s an excellent fit.

Primary Deployment (Headless Pi)

Directory Layout

/opt/vaultwarden/
├── docker-compose.yml
└── data/
    ├── db.sqlite3
    ├── attachments/
    └── config/

Only /opt/vaultwarden/data is backed up. Everything else is reproducible.

Docker Compose Configuration

version: "3.8"

services:
  vaultwarden:
    image: vaultwarden/server:latest
    container_name: vaultwarden
    restart: unless-stopped
    volumes:
      - /opt/vaultwarden/data:/data
    ports:
      - "127.0.0.1:8080:80"
    environment:
      WEBSOCKET_ENABLED: "true"
      ADMIN_TOKEN: "${ADMIN_TOKEN}"

Key decisions:

• Vaultwarden is bound to localhost only
• No direct LAN exposure
• Secrets live in an .env file
• Automatic restart after reboot

Admin Token & Hardening

Vaultwarden’s admin interface is disabled by default. I explicitly enable it using a strong token:

openssl rand -base64 48

This token is required to disable signups and manage security settings.

HTTPS With Caddy

Vaultwarden never handles TLS directly. Caddy acts as the HTTPS front door.

Caddyfile

vaultwarden.local {
    reverse_proxy 127.0.0.1:8080
}

This enforces HTTPS, isolates Vaultwarden from the network, and simplifies future expansion.

Local DNS (via Pi-hole) maps vaultwarden.local to the Pi’s IP.

Backup Strategy

MicroSD cards are convenient — and eventually unreliable. I treat the OS as replaceable and the data as sacred.

What Gets Backed Up

/opt/vaultwarden/data/

This includes:

• The SQLite database
• Attachments
• Configuration metadata

No disk images. No container layers.

Manual Backup (rsync)

rsync -av /opt/vaultwarden/data/ user@desktop-pi:/srv/backups/vaultwarden/

This runs over SSH and is easy to automate later with cron.

Fallback Node (Warm Standby)

The desktop Pi mirrors the primary configuration but remains offline.

Fallback Docker Compose

version: "3.8"

services:
  vaultwarden:
    image: vaultwarden/server:latest
    container_name: vaultwarden
    restart: unless-stopped
    volumes:
      - /opt/vaultwarden/data:/data
    ports:
      - "127.0.0.1:8080:80"
    environment:
      WEBSOCKET_ENABLED: "true"
      ADMIN_TOKEN: "${ADMIN_TOKEN}"

Identical configuration means no reconfiguration under stress and no client re-enrollment.

Disaster Recovery Procedure

If the primary Pi fails:

1. Restore the latest backup:

   rsync -av user@desktop-pi:/srv/backups/vaultwarden/ /opt/vaultwarden/data/


2. Start Vaultwarden:

   cd /opt/vaultwarden && docker-compose up -d


3. Update DNS so vaultwarden.local points to the desktop Pi.

4. Clients reconnect automatically.

Recovery time is measured in minutes.

Why This Design Works

• No split-brain risk (single active instance)
• Fast recovery using SQLite + Docker
• Hardware-independent restores
• Security preserved end-to-end
• Easy to test periodically

Lessons Learned

• Infrastructure should be boring, not clever
• Backups are useless without restore tests
• Bind mounts beat full-disk images
• Planning recovery ahead of time reduces stress dramatically

Final Thoughts

Self-hosting a password manager isn’t about distrust — it’s about ownership. Ownership of data, uptime, and recovery. This setup ensures that even if hardware fails, my digital identity doesn’t disappear with it.

If I never need the fallback Pi, that’s success.
If I do, I’ll be glad I treated resilience as a first-class feature.
